80 Way Electric Power Distro Box – 400A 3 Phase Touring Power Distribution

Professional Electric Power Distro Box for Stage and Touring Use

This 80 Way electric power distro box is built for demanding applications in live production, temporary installations, and industrial power setups. Designed to handle three-phase electric power at 400A, it’s an essential part of any reliable portable power distribution system.

With 72 Kupo 19-pin (Socapex-compatible) outputs and multiple CEE-form outputs, this stage power distro provides the flexibility and capacity needed for everything from major music festivals to film production power rigs.

Electric Power Distro Box Specifications and Outputs

Input and Through-Power – Camlock Power Distribution

• Camlock In & Out: 3 Phase, 400A, 380V (Camlock connector)

• Pass-through configuration for daisy-chaining multiple power distribution units

Socapex and CEE Outputs – Multi-Standard Power Access

• 72 × Kupo 19-pin 120V Outputs – compatible with Socapex stage lighting systems

• 6 × Weipu CEE 16A/3P 220V Outputs – for distributed equipment power

• 1 × Weipu CEE 32A/3P 220V Output – mid-range draw

• 1 × Weipu CEE 64A/3P 220V Output – for large-scale gear and sub-distros

Circuit Protection and Enclosure

• Main Breaker: Schneider 400A, 3-pin (Circuit breaker)

• Housing: Shock-mounted flight rack case – rugged and road-ready

• Breaker-isolated outputs for reliable and safe load management

Why Choose This Touring Power Box for Your Production Setup?

This touring power distro box is a professional-grade solution for distributing clean and stable electrical power to lighting, audio, and video systems. The mix of outputs makes it a central hub in large-scale portable power distribution configurations.

Whether you’re powering LED video walls, PA systems, or stage lighting, the 80-way layout ensures flexibility without compromising safety or organization.

Applications of Electric Power Distro Boxes in Real Scenarios

• Live Events: Supports power-hungry lighting and stage systems

• Touring Shows: Built for travel with shock-mounted protection

• Temporary Installations: Reliable for exhibition halls and festivals

• Industrial Power Distribution: Handles heavy-duty equipment in field environments

• Film and TV Production: Clean isolated channels for lighting, sound, and control gear

Using the Electric Power Distro Box Safely and Efficiently

1. Connect the Camlock input to a 3-phase 400A power source.

2. Activate the Schneider circuit breaker to initiate distribution.

3. Use Socapex and CEE outputs to feed individual equipment or subpanels.

4. Ensure proper grounding and phase balance for safe operation.

5. Use Camlock out for chaining to additional power distribution units

Customization, Ordering & Contact

We offer OEM modifications for this electric power distro box, including different connector layouts, voltages, and branding. Every unit is tested under load and certified to meet international power standards. For detailed quotes or drawings, please visit our contact page.
